Brand new e-bike frame with perfect integration of battery, drive unit and internal cabling, which at first glance differs minimally from a classic bike. The most power drive unit by Bosch CX Performance stands out for its extraordinary power, quiet operation and low weight. In combination with the 750 Wh battery, you get up to 150 km range from the bike in one charge. Shimano XT ensures trouble-free shifting. With the bike, you can ride even harder terrain thanks to DT Swiss suspension or high-quality Schwalbe tires. You will also appreciate the Acros BlockLock headset or dropper seatpost.
BASE INFO
| E-SYSTEM | BOSCH CX Performance, Battery PowerTube 750Wh |
| DISTANCE | 200km |
| MAX. TORQUE | 85Nm / 340% |
| SUPPORT UP TO SPEED | 25km/h |
| WEIGHT | 25.60 kg |
ISO and EN norm
| ISO norm | EN 15194 Standard for ‘Electronically Power Assisted Cycles’ (EPAC) |
| EN norm | EN17406 Condition 4 For rough Off-Road riding and jumpes less than 120cm |
| LOAD CAPACITY | 150 Kg |
E- BIKE PARTS
| MOTOR | BOSCH Performance Line CX, 85Nm |
| CHARGER | BOSCH 4A |
| BATTERY | BOSCH PowerTube, 750Wh |
| DISPLAY | BOSCH Mini Remote |
FRAMESET
| FRAME | SUE03-CXBES3, Alu X6 Ultralite MTB Trail, Advanced e-MTB Geometry, Travel 160/140 mm, BOSCH CX Performance 5G ready, Integrated battery up to 750Wh, 3D alloy one pice link, Alloy swingarm, Boost 12x148 mm, Inner cable routing, Dropped seat post ready |
| SUSPENSION FORK | DT Swiss F535, Tapered, 15x110mm axle, 160mm travel |
| REAR SHOCK | DT Swiss R535, size 230x65mm, OL |
| HEADSET | ACROS AZX-1051S, ICR, ZS56/28.6 - ZS56/40, BlockLock 120°, Stainless Bearings |
| REAR AXLE | SB02, TA12x171.5, M12xP1.0x14.5mm, Black |
DRIVETRAIN
| SHIFTERS RIGHT | SHIMANO DEORE XT SL-M8100-IR, RAPIDFIRE Plus, 12-speed |
| REAR DERAILLEUR | SHIMANO XT RD-M8100, Shadow Plus Design |
| CRANKSET | ONE Race, Alloy |
| CHAINRING | ONE Race, 34T |
| CASSETTE | SHIMANO DEORE CS-M6100, 12-speed, 10-51T |
| CHAIN | SHIMANO DEORE CN-M6100 |
BRAKING SYSTEM
| BRAKE FRONT | SHIMANO XT M8120, 4 piston, hydraulic disc brake |
| ROTOR FRONT | SHIMANO RT-MT800, 180mm |
| BRAKE REAR | SHIMANO XT M8120, 4 piston, hydraulic disc brake |
| ROTOR REAR | SHIMANO RT-MT800, 180mm |
WHEELS
| WHEELSET FRONT | DT Swiss H 1900 SPLINE®, CL, 15x110mm, Tubeless Ready |
| WHEELSET REAR | DT Swiss H 1900 SPLINE®, CL, 12x148mm, SH12, Tubeless Ready |
| TIRE FRONT | Schwalbe Nobby Nic Evo, SuperTrail, TL-Easy, 29x2.60", ADDIX SpeedGrip |
| TIRE REAR | Schwalbe Nobby Nic Evo, SuperTrail, TL-Easy, 29x2.60", ADDIX SpeedGrip |
COCKPIT
| STEM | ONE ICR, Alloy, 35mm, 0° |
| HANDLEBAR | ONE Alloy, 12mm rise, 35mm |
| GRIPS LEFT | ONE Race, Lock-On |
| GRIPS RIGHT | ONE Race, Lock-On |
PARTS
| SADDLE | Fizi:k Aidon X5, Alloy |
| SEATPOST LEVER | SHIMANO SL-MT500-L, Seat post lever |
| SEATPOST | ONE Sport Dropper Post, Alloy, 30.9mm |
| SEATPOST CLAMP | ONE CC-904A, 34.9mm, Full CNC mahined, Black |
⚡Superior eXF 9049 B, 2025, 750wh, "Olive / Black"
Artikelnummer: 8592842183864
CHF 7'299.00 Standardpreis
CHF 6'700.00Sale-Preis
